, , SKU: 500563

Hobart Champion® 145 Welder/Generator - 500563

(1 customer review)

-

For those who occasionally need and/or desire to weld, this stick welder/generator offers an all-in-one solution for portable power and welding, up to 4,500 watts​.

$2,499.00

Available offers

$100
Orders above $3000
View applicable products
Click to copy
100off
0 0
Days
0 0
Hours
0 0
Minutes
0 0
Seconds

Features and Benefits

Generator power

  • 4,500 watts surge power and 4,000 watts continuous power.

Large muffler

  • Quiet operation.

Briggs & Stratton Intek(TM) engine

  • No need for you to take breaks to fill up the tank. Fuel-efficient engine with 6.25-gallon fuel tank for longer run times.

Versatile receptacle package

  • With four 20A, 120 VAC GFCI receptacles and one 240 VAC (6-50R) receptacle with covers, allows you to obtain power for with 120 or 240 V tools or appliances.

145 amp DC welder

  • Allows you to weld DC stick electrodes up to 5/32 in. diameter.

Lightweight and rugged

  • Portable at 222 lb. (101 kg) with running gear and rollbar frame built for your added protection.

Specifications

PROCESSES

Stick (SMAW)

GENERAL SPECIFICATIONS

Title Champion® 145 Welder/Generator
Fuel Tank Size 6.25 gal.
Fuel Type Gasoline
Weldable Metals Steel
Stainless Steel
Specialty Metals
Rated Output 130 A @ 30% Duty Cycle
Single Phase Generator Continuous Power 4000 W
Single Phase Generator Peak Power 4500 W
Current Type DC
Amperage Range 40 – 145
Weld Output CC
Net Width 20.625 in
Net Height 24.75 in
Net Length 31.25 in
Net Weight 222 lbs
Warranty 3 Years

What's Included

  • Running Gear
Gtin 715959608930 SKU: 500563 Categories: , , Tag:
Weight 222 lbs
Dimensions 31.25 × 20.625 in
